XS4 Mini - ANSI

XS4 Mini - ANSI

Easy to install design makes the XS4 Mini a simple way for professionals to upgrade and replace mechanical-key-operated locks with the latest in electronic access control.

All new design technology

An easy to use electronic locking system that integrates all your physical security needs through networked, stand-alone battery operated smart locks, giving you all the latest users’ access information for virtually all of the doors in your facility.

Designed with the latest technologies to protect against advanced attacks, SALTO’s XS4 Mini technology leverages industry-leading security practices, including advanced encryption to provide users with a secure and seamless keyless experience.

Easy to install and retrofit

XS4 Mini ANSI wire-free electronic door lock blends attractive design and sophistication with strength and smart technology for your building.Unique design for easy retrofit, applicable to existing standard cylindrical or tubular door preparation, making it simple and fast to upgrade the traditional knob set without having to replace or drill the door.

Designed to fit your building’s needs

Superior structural integrity with a tough but sleek outer body, the XS4 Mini is a solution suitable for a wide range of customer applications, such as interior doors in education or commercial buildings, or tailored solutions for other specific building requirements.

Extensive tests and certificates set it apart, passing ANSI A156.2 Grade 1 and Grade 2 for the cylindrical and tubular versions, as well as UL10C listing.

Features

  • POWER SOURCE:

    • XS4 Mini: 3 alkaline batteries - LR03 - AAA 1,5V
    • Contactless versions: Up to 40,000 depending on the RFID technology.
    • Low battery power indication monitored through the SALTO Virtual Network (SVN).
    • The last approx. 1,000 operations are signalled.

    ENVIRONMENTAL CONDITIONS:

    • Not suitable for outdoor use.
    • Simple installation by changing handle set, reliable and durable.
    • SALTO SVN, SALTO BLUEnet Wireless network and JustIN Mobile technology inside.
    • Door status detector to monitor intrusions or door left open status (wireless escutcheons only).
    • User on card audit trailing capability via the SALTO Virtual Network (SVN).
    • Covering the mainstream RFID technologies.
    • NFC compatible.
    • All communication between the carrier and the electronic lock is encrypted and secured.
    • Low battery status information is obtained from carriers.
    • The lock can always be opened from the inside (single action panic feature works in conjunction with the relevant mortise lock).
    • High security protection via high resistance, hardened anti-drill plates to protect wiring and reader area.
    • Handle fixed by steady fix system (patented).
    • Concealed fixing screws for greater security and improved aesthetics.
    • Available with mechanical cylinder cut outs for key override or access lock outs.
    • Wide range of finishes, handles and retrofit cover plates.
    • Suitable for emergency exits.
    • Firmware upgrades wirelessly or through PPD.
    • Emergency opening via portable programming device (PPD).
  • USERS & DOORS:

    • Maximum number of users per door: 4 million.
    • Access levels: unlimited.

    CALENDARS & TIME ZONES:

    • Calendars in system: 256
    • Timetables: 1024
    • Time periods: 1024

    EVENTS:

    • Maximum events on lock audit: 2200(*).
    • Non volatile memory (memory is not deleted, even if power fails).

    ID TECHNOLOGIES:

    • Covering the mainstream RFID technologies.
    • Compatible with ISO 14443A, ISO 14443B and ISO 15693 (Vicinity).
    • Bluetooth-enabled and Near-field Communication (NFC) technology.
